Tables and overviews
19.4 Overview tables
19
628
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
Cycle
number Cycle designation DEF
active CALL
active
241 Single-lip deep-hole drilling
■
247 Datum setting
■
251 Rectangular pocket (complete machining)
■
252 Circular pocket (complete machining)
■
253 Slot milling
■
254 Circular slot
■
256 Rectangular stud (complete machining)
■
257 Circular stud (complete machining)
■
262 Thread milling
■
263 Thread milling/countersinking
■
264 Thread drilling/milling
■
265 Helical thread drilling/milling
■
267 Outside thread milling
■
Miscellaneous functions
M Effect Effective at block... Start End Page
M0 Program STOP/Spindle STOP/Coolant OFF
■
349
M1 Optional program run STOP/Spindle STOP/Coolant OFF
■
580
M2 Program run STOP/Spindle STOP/Coolant OFF/CLEAR status display
(depending on machine parameter)/Return jump to block 1
■
349
M3
M4
M5
Spindle ON clockwise
Spindle ON counterclockwise
Spindle STOP
■
■
■
349
M6 Tool change/STOP program run (depending on machine parameter)/
Spindle STOP
■
349
M8
M9
Coolant on
Coolant off
■
■
349
M13
M14
Spindle ON clockwise /coolant ON
Spindle ON counterclockwise/coolant on
■
■
349
M30 Same function as M2
■
349
M89 Vacant miscellaneous function or
cycle call, modally effective (depending on MPs)
■
■
Cycles
Manual
M91 Within the positioning block: Coordinates are referenced to machine
datum
■
350
M92 Within the positioning block: Coordinates are referenced to position
defined by machine tool builder, such as tool change position
■
350
M94 Reduce the rotary axis display to a value below 360°
■
436
M97 Machine small contour steps
■
353
M98 Machine open contours completely
■
354
M99 Blockwise cycle call
■
Cycles
Manual
