Tables and overviews
19.5 Functions of the TNC 640 and the iTNC 530 compared
19
636
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
Function TNC 640 iTNC 530
Graphic support
2-D programming graphics X X
REDRAW function – X
Show grid lines as the background X –
3-D line graphics X X
Test graphics (plan view, projection in 3 planes, 3-D
view) X X
High-resolution view X X
Tool display X X
Set the simulation speed X X
Coordinates of line intersection for projection in 3
planes – X
Expanded zoom functions (mouse operation) X X
Displaying frame for workpiece blank X X
Displaying the depth value in plan view during
mouse-over – X
Targeted stop of test run (STOP AT N) – X
Consideration of tool change macro – X
Program run graphics (plan view, projection in 3
planes, 3-D view) X X
High-resolution view X X
