Additional functions 9.8
9
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
291
FN 14: ERROR: Displaying error messages
With the function
FN 14: ERROR you can call messages under
program control. The messages are predefined by the machine tool
builder or by HEIDENHAIN. Whenever the TNC comes to a block
with
FN 14 in the Program Run or Test Run mode, it interrupts the
program run and displays a message. The program must then be
restarted. The error numbers are listed in the table below.
Range of error numbers Standard dialog text
0 ... 999 Machine-dependent dialog
1000 ... 1199 Internal error messages (see
table at right)
Example NC block
The TNC is to display the text stored under error number 254:
180 FN 14:ERROR = 254
Error message predefined by HEIDENHAIN
Error number Text
1000 Spindle?
1001 Tool axis is missing
1002 Tool radius too small
1003 Tool radius too large
1004 Range exceeded
1005 Start position incorrect
1006 ROTATION not permitted
1007 SCALING FACTOR not permitted
1008 MIRROR IMAGE not permitted
1009 Datum shift not permitted
1010 Feed rate is missing
1011 Input value incorrect
1012 Incorrect sign
1013 Entered angle not permitted
1014 Touch point inaccessible
1015 Too many points
1016 Contradictory input
1017 CYCL incomplete
1018 Plane wrongly defined
1019 Wrong axis programmed
1020 Wrong rpm
1021 Radius comp. undefined
1022 Rounding-off undefined
1023 Rounding radius too large
1024 Program start undefined
1025 Excessive nesting
