Technical Information 19.3
19
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
623
Accessories
■
One HR 550 FS portable wireless handwheel with display or
■
One HR 520 portable handwheel with display, or
■
One HR 420 portable handwheel with display or
■
One HR 410 portable handwheel, or
Electronic handwheels
■
One HR 130 panel-mounted handwheel, or
■
Up to three HR 150 panel-mounted handwheels via HRA 110
handwheel adapter
■
TS 220: triggering 3-D touch probe with cable connection, or
■
TS 440: 3-D touch trigger probe with infrared transmission
■
TS 444: Battery-free 3-D touch trigger probe with infrared transmission
■
TS 640: 3-D touch trigger probe with infrared transmission
■
TS 740: High-precision 3-D touch trigger probe with infrared
transmission
Touch probes
■
TT 140: 3-D touch trigger probe for tool measurement
■
TT 449: 3-D touch trigger probe for tool measurement with infrared
transmission
Hardware, options
■
1st additional axis for 4 axes plus spindle
■
2nd additional axis for 5 axes plus spindle
Software option 1 (option number 08)
Rotary table machining
■
Programming of cylindrical contours as if in two axes
■
Feed rate in distance per minute
Coordinate transformation
■
Working plane, tilting the ...
Interpolation
■
Circle in 3 axes with tilted working plane (spacial arc)
Software option 2 (option number 09)
■
Motion control with minimum jerk
■
3-D tool compensation through surface normal vectors
■
Using the electronic handwheel to change the angle of the swivel head
during program run without affecting the position of the tool point.
(TCPM =
T ool C enter P oint M anagement)
3-D machining
■
Keeping the tool normal to the contour
■
Tool radius compensation perpendicular to traversing and tool direction
Interpolation
■
Linear in 5 axes (subject to export permit)
HEIDENHAIN DNC (option number 18)
■
Communication with external PC applications over COM component
Display step (Option number 23)
■
Linear axes down to 0.01 µm Input resolution and display
step
■
Rotary axes to 0.00001°
