19.3 Technical Information
Explanation of symbols
■
Standard
□
Axis option
1 Software option 1
2 Software option 2
User functions
■
Basic version: 3 axes plus closed-loop spindle
■
Fourth NC axis plus auxiliary axis
or
Short description
□
8 additional axes or 7 additional axes plus 2nd spindle
■
Digital current and shaft speed control
Program entry In HEIDENHAIN conversational and ISO
■
Nominal positions for lines and arcs in Cartesian coordinates or polar
coordinates Position data
■
Incremental or absolute dimensions
■
Display and entry in mm or inches
■
Tool radius in the working plane and tool length Tool compensation
■
Radius compensated contour look ahead for up to 99 blocks (M120)
2 Three-dimensional tool-radius compensation for subsequent changing
of tool data without having to recalculate the program
Tool tables Multiple tool tables with any number of tools
Constant contour speed
■
With respect to the path of the tool center
■
With respect to the cutting edge
Parallel operation Creating a program with graphical support while another program is being
run
2 Motion control with minimum jerk
2 3-D tool compensation through surface normal vectors
2 Using the electronic handwheel to change the angle of the swivel head
during program run without affecting the position of the tool point.
(TCPM =
T ool C enter P oint M anagement)
3-D machining (software
option 2)
2 Keeping the tool normal to the contour
2 Tool radius compensation perpendicular to traversing and tool direction
Rotary table machining
(software option 1) 1 Programming of cylindrical contours as if in two axes
1 Feed rate in distance per minute
■
Straight line
■
Chamfer
■
Circular path
■
Circle center
■
Circle radius
Contour elements
■
Tangentially connected arc
