Feed rate factor for plunging movements: M103
Standard behavior
The TNC moves the tool at the last programmed feed rate,
regardless of the direction of traverse.
Behavior with M103
The TNC reduces the feed rate when the tool moves in the
negative direction of the tool axis. The feed rate for plunging
FZMAX is calculated from the last programmed feed rate FPROG
and a factor F%:
FZMAX = FPROG x F%
Programming M103
If you enter M103 in a positioning block, the TNC continues the
dialog by asking you the factor F.
Effect
M103 becomes effective at the start of block.
To cancel M103, program M103 once again without a factor.
M103 is also effective in an active tilted working
plane. The feed rate reduction is then effective during
traverse in the negative direction of the
tilted tool
axis.
Example NC blocks
The feed rate for plunging is to be 20% of the feed rate in the plane.
... Actual contouring feed rate (mm/min):
17 L X+20 Y+20 RL F500 M103 F20
500
18 L Y+50 500
19 L IZ-2.5 100
20 L IY+5 IZ-5
141
21 L IX+50 500
22 L Z+5
500
