Contents
26
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
7
Programming: Data transfer from DXF files or plain-language contours................................. 243
7.1
Processing DXF Files (Software Option)........................................................................................... 244
Application.............................................................................................................................................. 244
Opening a DXF file.................................................................................................................................245
Working with the DXF converter........................................................................................................... 245
Basic settings......................................................................................................................................... 246
Setting layers.......................................................................................................................................... 248
Defining the datum................................................................................................................................ 249
Selecting and saving a contour..............................................................................................................251
Selecting and saving machining positions............................................................................................. 255
