Tables and overviews
19.3 Technical Information
19
622
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
Specifications
Components
■
Operating panel
■
TFT color flat-panel display with soft keys
Program memory
■
Minimum 21 GB
■
Up to 0.1 µm for linear axes
■
Up to 0.01 µm for linear axes (with option 23)
Input resolution and display
step
■
Up to 0.0001° for rotary axes
■
Up to 0.000 01° for rotary axes (with option 23)
Input range
■
Maximum 999 999 999 mm or 999 999 999°
■
Linear in 4 axes
■
Circular in 2 axes
Interpolation
■
Helical: superimposition of circular and straight paths
■
Helical: superimposition of circular and straight paths
Block processing time
3-D straight line without radius
compensation
■
0.5 ms
■
Position loop resolution: Signal period of the position encoder/1024 Axis feedback control
■
Cycle time of position controller: 3 ms
■
Cycle time of speed controller: 200 µs
Range of traverse
■
Maximum 100 m (3937 inches)
Spindle speed
■
Maximum 100 000 rpm (analog speed command signal)
Error compensation
■
Linear and nonlinear axis error, backlash, reversal peaks during circular
movements, thermal expansion
■
Stick-slip friction
■
One each RS-232-C /V.24 max. 115 kilobaud
■
Expanded interface with LSV-2 protocol for external operation of the
TNC over the interface with HEIDENHAIN software TNCremo
Data interfaces
■
Ethernet interface 1000 Base T
■
3 x USB 2.0
Ambient temperature
■
Operation: 0 °C to +45 °C
■
Storage: –30 °C to +70 °C
