Programming: Subprograms and program section repeats
8.6 Programming examples
8
276
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
14 CYCL DEF 201 REAMING Cycle definition: REAMING
Q200=2 ;SET-UP CLEARANCE
Q201=-15 ;DEPTH
Q206=250 ;FEED RATE FOR PLNGNG
Q211=0.5 ;DWELL TIME AT DEPTH
Q208=400 ;RETRACTION FEED RATE
Q203=+0 ;SURFACE COORDINATE
Q204=10 ;2ND SET-UP CLEARANCE
15 CALL LBL 1 Call subprogram 1 for the entire hole pattern
16 L Z+250 R0 FMAX M2
End of main program
17 LBL 1
Beginning of subprogram 1: Entire hole pattern
18 L X+15 Y+10 R0 FMAX M3 Move to starting point for group 1
19 CALL LBL 2
Call subprogram 2 for the group
20 L X+45 Y+60 R0 FMAX Move to starting point for group 2
21 CALL LBL 2 Call subprogram 2 for the group
22 L X+75 Y+10 R0 FMAX
Move to starting point for group 3
23 CALL LBL 2 Call subprogram 2 for the group
24 LBL 0 End of subprogram 1
25 LBL 2
Beginning of subprogram 2: Group of holes
26 CYCL CALL 1st hole with active fixed cycle
27 L IX+20 R0 FMAX M99 Move to 2nd hole, call cycle
28 L IY+20 R0 FMAX M99
Move to 3rd hole, call cycle
29 L IX-20 R0 FMAX M99 Move to 4th hole, call cycle
30 LBL 0 End of subprogram 2
31 END PGM UP2 MM
