Column Meaning
RAD Tool radius R + Oversize of tool radius
DR from the tool table. (in mm)
BLOCK
Block number in which the
TOOL CALL
block was programmed
PATH TOKEN = TOOL: Path name of the active
main program or subprogram
TOKEN = STOTAL: Path name of the
subprogram
T
Tool number with tool index
OVRMAX
Maximum feed rate override that occurred
during machining. During Test Run the
TNC enters the value 100 (%)
OVRMIN Minimum feed rate override that occurred
during machining. During Test Run the
TNC enters the value –1
NAMEPROG
0: The tool number is programmed
1: The tool name is programmed
There are two ways to run a tool usage test for a pallet file:
The highlight in the pallet file is on a pallet entry: The TNC runs
the tool usage test for the entire pallet
The highlight in the pallet file is on a pallet entry: The TNC runs
the tool usage test for the entire pallet
