Tool data 5.2
5
TNC 640 | User's Manual
HEIDENHAIN Conversational Programming | 5/2013
175
Tool change
The tool change function can vary depending on
the individual machine tool. Refer to your machine
manual.
Tool change position
The tool change position must be approachable without collision.
Use the miscellaneous functions
M91 and M92 to enter machine-
based (rather than workpiece-based) coordinates for the tool
change position. If
TOOL CALL 0 is programmed before the first
tool call, the TNC moves the tool spindle in the tool axis to a
position that is independent of the tool length.
Manual tool change
To change the tool manually, stop the spindle and move the tool to
the tool change position:
Move to the tool change position under program control
Interrupt program run (See "Interrupt machining", page 572)
Change the tool
Resume program run (See "Resuming program run after an
interruption", page 573)
Automatic tool change
If your machine tool has automatic tool changing capability,
the program run is not interrupted. When the TNC reaches a
TOOL CALL it replaces the inserted tool by another from the tool
magazine.
Automatic tool change if the tool life expires: M101
The function of
M101 can vary depending on the
individual machine tool. Refer to your machine
manual.
When the specified tool life has expired, the TNC can automatically
insert a replacement tool and continue machining with it. Activate
the miscellaneous function
M101 for this. M101 is reset with
M102.
