CiM-300L IP Enabled Satellite Modem Rev. 1
Front Panel Menus CD/CIM300L.IOM
54
4.2.1.1.6 Function Select – Utility
DISPLAY SELECTIONS/DESCRIPTION
FUNCTION SELECT
UTILITY
MODULATOR
DEMODULATOR
INTERFACE
SYSTEM
MODEM TYPE
FACTORY SET-UP
Utility – Modulator
DISPLAY SELECTIONS/DESCRIPTION
UTILITY
MODULATOR
ASSIGN
TRANSMIT FILTERS
Transmit code rate/type selection. Select one
of the following or a variable rate selection (V),
as follows:
TX-x QPSK 1/2
Code Rate Data Rate Range
BPSK 1/2 2.4 to 1250 kbit/s
QPSK 1/2 4.8 to 2500 kbit/s
QPSK 3/4 7.2 to 3750 kbit/s
QPSK 7/8 8.4 to 4375 kbit/s
8PSK 2/3 64 to 5000 kbit/s
OQPSK 1/2 4.8 to 2500 kbit/s
OQPSK 3/4 7.2 to 3750 kbit/s
OQPSK 7/8 8.4 to 4375 kbit/s
BPSK 1/1 4.8 to 2500 kbit/s
QPSK 1/1 9.6 to 5000 kbit/s
Notes: 1. Max Symbol Rate: 2500 kbit/s
2. Max Data Rate for Low Var Rate:
512.0 kbit/s.
TX TERMINAL LO
0 MHz MIX:-
Enter: “+” for high mix
Or
“-” for low mi
MOD POWER OFFSET
0.0 dB
Modulator power offset adjust. Offsets the
modulator output power readout in the
Configuration menu. This feature does not
actually change the modulator power level,
but displays an offset value in the monitor.
The modulator power offset range is -99.9 to
+99.9 dB, in 0.1 dB steps.
Note: Anything except 0.0 dB will cause ADJ
to be displayed for the TX power level
