CiM-300L IP Enabled Satellite Modem Rev. 1
Web Server Pages CD/CIM300L.IOM
207
Field Description
Dropped – Bad IP Version The CiM only supports Ipv4. The first four bites of the IP header
field (specifies IP Version) are checked.
Dropped – Miscellaneous Catch all bucket for packets experiencing non-standard
problems.
Dropped – QOS Packet was dropped because for a particular route (that it
matched) the maximum bandwidth has been exceeded.
Dropped – QOS buffers Packet was dropped because the buffers used to store QOS
packets have been exhausted.
Dropped – Dropped buffers Packet dropped because the CiM’s buffers have exhausted.
This will usually occur when the packet rate through the CiM
has exceeded the factory defined limitiations.
Reset Counters Executing this menu option resets all statistics gathered for the
receiver to zero.
Save Parameters This option allows a user to save the current configuration of
the CiM to permanent storage. This configuration will be
restored on each successive power cycle of the CiM.
Exit This option allows a user to exit the current menu and return to
its parent menu.
