CiM-300L IP Enabled Satellite Modem Rev. 1
Serial Remote Control CD/CIM300L.IOM
82
Parameter Type Protocol Description
Demodulator
Rate Status Command:
Response:
>add/DR_nnnn_mmmm.mmm'cr''lf']
Where:
nnnn = 1/2 (QPSK 1/2), [coder rate], 3/4 (QPSK 3/4), 7/8 (QPSK
7/8), BP12 (BPSK 1/2), 8P23 (8PSK 2/3), (OQ12 (OQPSK 1/2),
OQ34 (OQPSK 3/4), OQ78 (OQPSK 7/8)
mmmm.mmm = Data rate in kHz.
Receive
Signal Level
Status Command:
Response:
>add/RSL_xsnn.ndBm'cr''lf']
Where:
x = < or > (data modifier to indicate that the receive signal level is
less than or greater than the returned value).
s = + or - (receive signal level sign, plus or minus).
nn.n = 0.0 to 99.9 (receive signal level magnitude).
Notes: 1. The 'x' (< or >) parameter is only returned if the level
has exceeded the computational resolution of the
system.
2. 'No Data' is returned if the level cannot be calculated.
3. Sampling' is returned if not enough data is currently
available to calculate the level.
LNB Current
Monitor
Status Command:
Response:
>add/LNBC_nnn'cr''lf']
Where: nnn = 0 to 500 (in 1 mA steps)
Notes: 1. The 'x' (< or >) parameter is only returned if the level
has exceeded the computational resolution of the
system.
2. 'No Data' is returned if the level cannot be calculated.
3. Sampling' is returned if not enough data is currently
available to calculate the level.
Current
Sweep Value Command:
Response:
>add/CSV_xsnnnnn'cr''lf]
Where:
x = < or > (data modifier to indicate that the sweep offset value is
less than or greater than the returned value).
s = + or - (sweep offset from center).
nnnnn = 0 to 35000.
yyy = OK or FLT (decoder lock status OK or FAULT).
Notes: 1. The 'x' (< or >) parameter is only returned if the level
has exceeded the computational resolution of the
system.
2. 'No Data' is returned if the level cannot be calculated.
3. 'Sampling' is returned if not enough data is currently
available to calculate the level.
