background image

CiM-300L IP Enabled Satellite Modem

Rev. 1

CLI & Telnet

CD/CIM300L.IOM

166

Menu Options/Fields

Entry Description

ODU Current Threshold
HIGH (mA)

H

Valid Ranges are from 0 to 4000, in multiples of 100.

LNB Power

U

1 - OFF
2 - ON

LNB Voltage

V

1 - OFF
2 - ON

LNB Reference Enable

W

1 - OFF
2 - ON

LNB Current Threshold
LOW (mA)

Y

Valid ranges are from 0 to 500 mA.

LNB Current Threshold
HIGH (mA)

Z

Valid ranges are from 0 to 500 mA.

Save Parameters

S

This option allows a user to save the current
configuration of the CiM to permanent storage. This
configuration will be restored on each successive
power cycle of the CiM.

Exit

X

This option allows a user to exit the current menu and
return to its parent menu.
