CiM-300L IP Enabled Satellite Modem Rev. 1
Introduction CD/CIM300L.IOM
4
Option
Description & Comments Install
Option
Quality of Service (QoS) Available now (1.0.1 and Later) Fast
Network Address Translation
(NAT) Future Feature (2.0.1) Fast
Transparent bridging for non-IP
traffic Future Feature (2.0.1) Fast
IGMP support for multicast Available now (1.0.1 and Later) Fast
-30 to -5 dBm IF output (low
power) Output 2nd Harmonics:
< 45 dBc at data rates < 64 kbps
< 50 dBc at data rates ≥ 64 kbps Factory
8PSK, 2/3 rate, EFD Mode Requires Viterbi Codec Fast
Primary Power: 48 Vdc Future Factory
Primary Power: Auto-ranging
AC 85 to 264 Vac Available now Factory
ODU DC Power: 15V, 24V, 28V
or 48V. Primary input = AC
Only 3 Amps maximum or less depending upon
power supply. Factory
1.4 M
ONITORING
F
EATURES
The unit's monitoring features include:
! Interface Loopback – at the MOD and DEMOD interface (Bi-directional)
! BER, Eb/No, Buffer Fill Percentage
! IF Loopback
1.5 C
OMPATIBILITY
The CiM-300L, when properly configured, the unit will interoperate with the following
Comtech EF Data modems:
! CiM-550
! CiM-560
