2. Set-up and Connection Technical Reference Manual-4.0.0en
2.14 Using the Minipack
The Minipack has several features
which may not be readily apparent at
first. These features help to make
using System 500 more comfortable. 2. Hip Belt
The Hip Belt transfers most of the
weight from the shoulders to the hips
when properly adjusted.
It also contains velcro attachments
through which cables can be passed.
Use the attachments as shown in the
photograph.
1. Antenna Pole Strap
Ensures the Antenna Pole does not
sway around and remains as upright
as possible.
Pass the strap around the pole and
fasten using the clip as shown in the
photograph.
