324 Appendix D Technical Reference Manual-4.0.0en
Appendix D - Defined Line File Format
Lines that have been defined in Stakeout are stored in the
file STK_Line.txt in the data directory of the memory
device. Up to 100 lines may be stored in this file.
Line records take the following format, separator is a
space, but no space after
@< and @> . The linear unit is
Meter and the angular unit is Gon.
@@>LD LDD
Record Format
@<
ID
xxxxx.xxx
yyyyy.yyy
hhh.hhh
@>
LD
LDD
Description
Start of first line of record
Line ID, 16 characters
Start Point Easting
Start Point Northing
Start Point Orthometric Height
Start of second line of record
Line definition type:
1 - Endpoint Easting, Northing, Height
2 - Distance, Bearing, %V
3 - Distance, Bearing, H/V
4 - Distance, Bearing, V/H
5 - Distance, Bearing, Hgt Diff
Line definition values. Depend on LD, as
shown above.
} }
{ { {
8 7 6
5 4 3 2 1
LDD LD @
hhh.hhh yyyyy.yyy xxxxx.xxx ID @
>
<
48 47 6 4 4 8 4 4 7 6 4 4 8 4 4 7 6
