35
2. Set-up and Connection Technical Reference Manual-4.0.0en
2.6 Equipment Setup - Post Processed Kinematic, All on Pole, TR500 and Sensor separated
Use
Post-processed Kinematic Rover.
The TR500 is fixed to the pole grip with a holder. With
another metallic holder and a holder piece, the receiver is
fixed to the pole. One connection is made from the Re-
ceiver to the Antenna. Another connection is made from
the Receiver to the TR500. Recommended for short
periods of use, especially where there are many obstacles
(fences etc.).
Assumptions
1. GPS Antenna is mounted directly using screw fitting.
If using stub and GAD 31 adapter, procedures may
vary slightly.
2. Aluminium poles are used. You may replace them
with their Carbon Fiber equivalents without any
change to these instructions.
