37
2. Set-up and Connection Technical Reference Manual-4.0.0en
How to set up the equipment
1. Screw the two halves of the pole
together.
2. Slide the grip onto the pole.
Attach the TR500 holder to the
grip and tighten the screw.
3. Slide the holder piece for the
GPS Receiver onto the pole.
Attach the GPS Receiver holder
and tighten the screw.
4. Screw the GPS Antenna onto
the top of the pole.
5. Slide the TR500 into the holder
until it clicks into place.
6. Screw the GPS Receiver to the
GPS Receiver holder.
7. Insert the PC Card into the
Receiver and plug in the
GEB121 batteries.
8. Connect the GPS Antenna to the
Receiver using the antenna
cable supplied with the GPS
receiver holder piece.
9. Connect the TR500 to the port
labelled “Terminal” on the
Receiver using the 5 pin Lemo
cable.
10. Switch on the system using the
ON/OFF button on the TR500.
The Next Steps
If the Receiver has been pre-pro-
grammed and the TR500 is being
used, further guidance is available in
Chapter 7.
If the Receiver requires programming
with the TR500, further guidance is
available in Chapter 5.
When using the upper pole
halves with stub, ensure that
the Antenna and GAD31 screw/stub
adapter slide down the full length of
the stub before tightening the locking
ring. An incorrectly mounted Antenna
will have a direct effect on your
results.
