53
2. Set-up and Connection Technical Reference Manual-4.0.0en
How to set up the equipment
Follow steps 1-9 described in section
2.6.
10. Attach the Radio Modem in its
housing to the GPS Receiver.
11. Screw the Radio Antenna onto
the housing.
12. Switch on the system using the
ON/OFF button on the TR500.
The Next Steps
If the Receiver has been pre-pro-
grammed and the TR500 is being
used, further guidance is available in
Chapter 7.
If the Receiver requires programming
with the TR500, further guidance is
available in Chapter 5.
When using the upper pole
halves with stub, ensure that
the Antenna and GAD31 screw/stub
adapter slide down the full length of
the stub before tightening the locking
ring. An incorrectly mounted Antenna
will have a direct effect on your
results.
