9. The CONFIG Key

Technical Reference Manual-4.0.0en

9.3 General - Language

Select the Language in which you
wish the Terminal Interface to be
displayed. The language is
associated with the Configuration Set.

The Receiver can hold up to two
languages.Use the DEL (F4) key to
delete any languages that are not
required.

9.4 General - Hot Keys

You may assign a particular screen to
each of the keys F7 - F10 so that
when one of these keys is pressed,
that screen is displayed.

Select the key you wish to configure
and press ENTER. A list of all
available screens is displayed. Select
the screen and press ENTER.

Note that you can also configure the
function keys F1 - F6 to the hot keys
or select ‘NEXT Dialog Call’ to switch
between all previously opened
screens.
