44 2. Set-up and Connection Technical Reference Manual-4.0.0en
Use
The Radio Modem attaches to the Receiver and is placed
in the Minipack. Connections are made to the GPS
Antenna, Radio Antenna and TR500. Recommended for
extended periods of use in the field.
The cables coming from the Minipack can be discon-
nected in the event that an obstacle (E.g. a fence) has to
be crossed.
Assumptions
1. GPS Antenna is mounted directly using screw fitting.
If using stub and GAD 31 adapter, procedures may
vary slightly.
2. Aluminium poles are used. You may replace them
with their Carbon Fiber equivalents without any
change to these instructions.
2.9 Equipment Setup - Real-Time Rover, Pole and Minipack
