Connecting the Power and Communication Cables
Installation Guide | 77
To connect the power and communication cables
1. If you have not already done so, insert the end of the touch screen cable into
the touch screen connection port on the back of the instrument.
2. Insert the Cat 6 (or higher) cable into the ethernet port on the back of the
instrument.
3. (Optional) Connect the power cords for any peripheral instruments into the
power outlet ports.
4. Connect the power cable to the power inlet port.
5. If installing the NGC instrument into a standard cold cabinet, direct the
following cables through the access port on the side of the cabinet:
 Touch screen cable
 Ethernet cable
 Power cable (if your cabinet does not have a power outlet)
6. Press the I/O power switch to the On position.
Caution: The weight of the NGC instrument varies from moderate to
heavy depending on the system. Take care when lifting the instrument into
the cold cabinet. To reduce the risk of personal injury or damage to the
instrument, three or more people should perform this task.
7. If installing the NGC instrument into a standard cold cabinet:
a. Lift the instrument into position.
b. Connect the power cable to the power outlet.
