3 | Setting Up NGC Chromatography Systems
26 | NGC Chromatography Systems and ChromLab Software
4. Using two ¼-20 x ¾" hex bolts and the hex key labeled pumphead provided in
the NGC accessories kit, attach the touch screen mount to the side of the NGC
instrument.
5. Slide the touch screen display onto the mounting post.
6. Insert a ¼-20 x ¾" hex bolt underneath the mount to secure the touch screen.
