Attaching the Touch Screen
Installation Guide | 35
4. Complete the steps in the section To connect the power and communication
cables on page 77 .
To place the instrument in the cold cabinet
Caution: Two or more individuals should lift the instrument.
 Carefully lift the instrument into the cold cabinet. See the packaging insert for
information about lifting the NGC instrument.
To attach the touch screen to the touch screen stand
1. Place the touch screen monitor face down on a clean surface to prevent
scratching.
2. Using the 7/64 hex key provided in the accessories kit, remove the cover from
the back of the touch screen monitor.
