Plumbing NGC Systems
Installation Guide | 109
Plumbing the NGC Scout System
Table 10 lists the tasks for plumbing the NGC Scout™ system. The tasks are
explained in detail in the sections that follow.
Note: Ensure that you complete the plumbing tasks in the section Plumbing All
NGC Systems on page 100 before continuing.
1. Inlet tubing to ports Q1–Q4 on the buffer blending valve
2. Waste tubing to the calibration outlet port (Cal Out) on the pH valve
3. Pump head wash priming line to the calibration inlet port (Cal In) on pH
valve
4. Tube #2 from the 40 psi backpressure regulator to the inlet port on the
pH valve
5. Tube #4 from the outlet port on the pH valve to the Common inlet port on
the BioFrac fraction collector diverter valve
The figure on page 110 shows the Point-to-Plumb connections for the NGC Scout
system.
Table 10. Plumbing tasks for the NGC Scout system
NGC Scout
