Troubleshoot an EtherNet/IP Communication Module with Diagnostic Web Pages Chapter 10
Rockwell Automation Publication ENET-UM001L-EN-P - March 2014 129
Troubleshoot an EtherNet/IP Communication Module with Diagnostic Web Pages Chapter 10
Troubleshoot the
1756-EN2TR Communication
Module Use this table to determine what diagnostic web page to use when you
troubleshoot issues on your module.
Table 33 - Required Diagnostic Web Pages
Technical Issue Diagnostic Web Page
CPU utilization Diagnostic Overview
CIP connection statistics
TCP connections
HMI/MSG statistics
I/O and produce/consume packets per second
I/O and produce/consume packet counts
Link status Ethernet Statistics
Speed
Duplex
Autonegotiate status
Ethernet errors
Connections closed due to a Timeout Choose this path to tab:
Diagnostics>Advanced Diagnostics>Miscellaneous>System
Data>Connection Manager Cmd Object Info
Network topology Ring Statistics
Network status
Ring supervisor statistics
Ring supervisor IP address or MAC ID
IMPORTANT The 1756-EN2TR communication module has two ports. Some diagnostics are
tracked for Port 1 and Port 2 because the values may be different between
ports.
