Chapter 9 Diagnostic Web Pages
Ethernet Statistics
Table 29 - Diagnostic Overview Web Page
Field Specifies
Ring Status
Network Topology Whether the Ethernet network is linear or DLR topology.
Network Status Whether the Ethernet network is operating normally or otherwise.
Ring Supervisor The IP and MAC address of the ring supervisor.
Beacon Interval Beacon interval values. These values affect network recovery time. Use default values unless the ring includes more than 50
devices. For more information, refer to the EtherNet/IP Embedded Switch Technology Application Guide, publication
ENET-AP005 .
Beacon Timeout Beacon timeout values. These values affect network recovery time. Use default values unless the ring includes more than 50
devices. For more information, refer to the EtherNet/IP Embedded Switch Technology Application Guide, publication
ENET-AP005 .
System Resource Utilization Number of times a page has been requested for which the user has insufficient privilege.
CPU Current percent CPU utilization for the module.
CIP Connection Statistics
Current CIP MSG Connections Current number of CIP connections for message.
Current CIP I/O Connections Current number of CIP connections for I/O.
Conn Timeouts Number of CIP connection timeouts.
TCP Connections (CIP)
Active Current number of active TCP connections for CIP messaging.
