Diagnostic Web Pages Chapter 9
This table describes the fields most commonly used on the Diagnostics Overview
web page.
Table 24 - Diagnostic Overview Web Page
Field
Specifies
Module Resource Utilization (All Ports)
CPU
Current percent CPU utilization for the module
CIP Connection Statistics (All Ports)
Active Total
Total number of active CIP connections used for both messaging and I/O
TCP Connections (EtherNet/IP Port)
Active
Number of active TCP connections for CIP messaging
HMI/MSG (EtherNet/IP Port - Class 3)
Sent packets per second
Number of Class 3 TCP packets sent in the last one-second snapshot
Received packets per second
Number of Class 3 TCP packets received in the last one-second snapshot
I/O and Prod/Cons Packets Per Second (EtherNet/IP Port - Class 1)
Total
Total number of Class 1 UDP packets sent and received
I/O and Prod/Cons Packets Count (EtherNet/IP Port - Class 1)
Missed
Number of Class 1 UDP packets missed
