Chapter 5
Visualization
The faceplates provide the following information:
• Tag name from instrument
• Description from instrument
• Engineering units from instrument
• Typical analog process values (PV)
• Analog fault status (channel fault, broken wire, module fault)
• HART PV (first, second, third)
• HART PV fault status (first, second, third, fourth)
• HART PV range (minimum and maximum)
• HART command 48 diagnostic information
Configure the faceplates to provide the following:
• Mode (such as operator or program)
• High-high, high, low, and low-low alarms
• Over-range and under-range alarms
• Alarm delay
• Alarm hysteresis
IMPORTANT
A unique global object and faceplates are available for each field instrument
due to the display of instrument-specific diagnostic information.
