Appendix I
Deltabar S Differential Pressure
Configure a Deltabar S
Differential Pressure
You can configure the device via the local display and menus on the instrument.
On the local display of the field instrument, use the Quick Setup menus to
configure instrument parameters.
Flow Measuring Mode
Level Measuring Mode
1)
2)
1)
1)
1) Display via on-site display only
2) Display via ToF Tool, FieldCare and
HART handheld terminal only
MAX FLOW
MAX. PRESS. FLOW
POS. ZERO ADJUST
DAMPING VALUE
Flow
Pressure
Level
OPERATING MENU
Measured value
GROUP SELECTION
LANGUAGE
MEASURING MODE
QUICK SETUP
MEASURING MODE
1)
2)
1)
1)
3)
3)
LEVEL SELECTION
3) – LEVEL SELECTION "Level Easy Pressure" and
CALIBRATION MODE "Wet"
– LEVEL SELECTION = "Level Standard",
LEVEL MODE = "Linear" and
CALIBRATION MODE = "Wet"
POS. ZERO ADJUST
EMPTY CALIB.
FULL CALIB.
DAMPING VALUE
Pressure
Level
OPERATING MENU
Measured value
GROUP SELECTION
LANGUAGE
MEASURING MODE
QUICK SETUP
MEASURING MODE
1) Display via on-site display only
2) Display via FieldCare and
HART handheld terminal only
LEVEL SELECTION
Flow
