Page 16

16
Rockwell Automation Publication PROCES-UM002A-EN-P - July 2014
Chapter 1
Installation
Figure 5 - 2-Wire Connection to 1769sc-IF4IH Input Module
Figure 6 - 2-Wire Connection to 1734sc-IE2CH Input Module
Figure 7 - 2-Wire Connection to 1734sc-IE4CH Input Module
N/C
Ch1-iRtn
N/C
Ch3-iRtn
Ch0+
N/C
Ch0-iRtn
Ch0-
Ch1+
N/C
Ch2-iRtn
Ch2-
Ch3+
Ch3-
N/C
N/C
Ch2+
Ch1-
+ -
2 Wire
XMTR
+
-
24V DC
Power
Supply
2 Wire Current Input
0
IN 0
2
+ 24
4
COM
6
FGN
1
IN 1
3
+ 24
5
COM
7
FGN
2 Wire
Device
0
IN 0
2
IN 2
4
COM
6
FGN
1
IN 1
3
IN 3
5
+ 24
7
FGN
2 Wire
Device
