Wiring
Chapter 8
8-77
Motor and Drive Power Wiring
In accordance with NEC, the power wiring size should be based on the 30
minute overload rating of the applicable motor. The user must determine if
national or local codes specify other requirements. All power wiring should
be terminated to the bolt or screw terminals on the drive and motor using
ring type terminal lugs.
ATTENTION: To guard against the hazard of personal injury
or damage to equipment, the interconnections to the motor and
feedback device must be made as explained in this chapter.
Failure to do so could cause loss of motor control and/or severe
oscillation of the motor shaft.
!
The size of the power terminal connections on the drive for incoming AC
line power and motor power terminations is shown below.
Table 8.A
Power Terminal Sizes
Drive Catalog Number
8510A-A04-x1
8510A-A06-x1
8510A-A11-x2
8510A-A22-x2
Bolt / Screw
Size
M4
M4
M6
M8
Maximum Lug
Width
10.8 mm (0.425 in.)
10.8 mm (0.425 in.)
17.0 mm (0.668 in.)
17.0 mm (0.668 in.)
The size of the power terminal connections in the motor terminal box for
motor power is shown in Table 8.B.
Table 8.B
Motor Terminal Sizes
Motor Catalog
Number
1327AC-AFM-02-F
1327AC-AFM-04-x
1327AC-AFM-06-x
1327AC-AFL-08-x
1327AC-AFL-11-x
1327AB-AFL-15-x
1327AB-AFL-19-x
1327AB-AFL-22-x
1327AD-ABL-04-x
1327AD-ABL-06-x
1327AD-ABL-08-E
1327AD-ACL-08-F
1327AD-AAK-11-x
1327AD-AAK-15-x
1327AD-AAK-19-x
Bolt / Screw
Size
M5
M5
M5
M6
M6
M8
M8
M8
M8
M8
M8
M8
M8
M10
M10
Maximum Lug
Width
13 mm
13 mm
13 mm
17 mm
17 mm
24 mm
24 mm
24 mm
23 mm
23 mm
23 mm
23 mm
23 mm
29 mm
29 mm
To minimize radiated PWM noise, the individual motor phase wires must
be part of a single multi-conductor cable or run very close together. The
motor cables should be contained in grounded metal conduit or raceways.
