Troubleshooting

Chapter 11

11-132

Table 11.H (Continued)
Other Faults that Indicate Control Hardware Malfunction

Possible Solutions

Probable Cause

Problem

Main CPU1 Err
displayed - The
master cpu on the
Main Control Board
(CPU Board on
A04/A06 drive)
malfunctioned.

1. Verify that EPROM chip on Main Control Board (CPU Board on

A04/A06 drive) is inserted correctly.

2. If problem remains, replace Main Control Board (CPU Board on

A04/A06 drive).

Hardware malfunction.

Main CPU2 Err
displayed - The
slave cpu on the
Main Control Board
(CPU Board on
A04/A06 drive)
malfunctioned.

1. Verify that EPROM chip on Main Control Board (CPU Board on

A04/A06 drive) is inserted correctly.

2. If problem remains, replace Main Control Board (CPU Board on

A04/A06 drive).

Hardware malfunction.

Main RAM Init
displayed- Function-
al error detected in
RAM on Main
Control Board (CPU
Board on A04/A06
drive).

Replace Main Control Board (CPU Board on A04/A06 drive).

Hardware malfunction.

No.

Main CPU Ovfl
displayed - CPU on
Main Control Board
(CPU Board on
A04/A06 drive).ran
out of execution
time.

Firmware error or hardware
malfunction.

1. Verify that both EPROMs on I/O Board and Main Control Board

are inserted correctly.

2. If problem remains, replace Main Control Board (CPU Board on

A04/A06 drive). If problem recurs, contact Allen-Bradley.

Optical Intpt
displayed - A system
interrupt was sensed
through the test
system fiber optic
transducer.

Bright flash of light triggered the
fiber optic input.

1. Assure that the rubber plug is installed in the fiber optic

connector on the Main Control Board (CPU Board on A04/A06
drive). The fiber optic connector is located adjacent to connector
CN2.

2. If problem remains, replace Main Control Board (CPU Board on

A04/A06 drive).

Hi Accel Rate
displayed

Firmware error.

Reset drive. If fault persists, contact Allen-Bradley.

Hi Positn Cmd
displayed

Firmware error.

Reset drive. If fault persists, contact Allen-Bradley.

Hi Positn Err
displayed

Firmware error.

Reset drive. If fault persists, contact Allen-Bradley.

Hi Speed Cmd
displayed

Firmware error.

Reset drive. If fault persists, contact Allen-Bradley.

I/O Board Faults

When problems occur with the I/O Board, the first line of the display will
show either !Fault I/O Board or Warning I/O Brd. The second line provides
more detailed information about the exact nature of the fault.
