8510sa, P11 m, A04 f – Rockwell Automation 8510 AC Spindle Drive System User Manual User Manual
Page 45
Receiving, Unpacking and Inspection
Chapter 4
4-41
Drive Mounting Adapters
8510SA
First Position
Second Posi-
tion
Bulletin
Number
Mounting
Adapter
P11
M
–
Third Position
Adapter
Components
Description
Brackets to panel mount the A04 drive inside an
enclosure
Brackets to panel mount the A06 drive inside an
enclosure
Brackets to panel mount the A11 drive inside an
enclosure
Brackets to panel mount the A22 drive inside an
enclosure
Panel mounting brackets plus adapter to allow
ducting cooling air from side of enclosure to an
A04 drive
Panel mounting brackets plus adapter to allow
ducting cooling air from side of enclosure to an
A06 drive
Panel mounting brackets plus adapter to allow
ducting cooling air from side of enclosure to an
A11 drive
Panel mounting brackets plus adapter to allow
ducting cooling air from side of enclosure to an
A22 drive
Code
P04
P06
P11
P22
V04
V06
V11
V22
AC Line Fuse Kits
8510SA
First Position
Second Posi-
tion
Bulletin
Number
Fuse &
Fuse Block
A04
F
–
Third Position
Fuse Ratings
Description
Fuses & fuse blocks for A04 drive
Fuses & fuse blocks for A06 drive
Fuses & fuse blocks for A11 drive
Fuses & fuse blocks for A22 drive
Code
A04
A06
A11
A22
