Specifications
Chapter 2
2-10
Standard Single Speed 1327AB Motor & 8510 Drive
Motor 1327AB -
Output Power Rating S1 - Continuous - kW (HP)
S2 - 30 Minute - kW (HP)
1
S6 - 60% Duty - kW (HP) 2
1 Minute Peak - kW (HP)
Rated Speed Base RPM
Maximum RPM
Constant Power/Speed Range
Rated Torque Continuous N-m (lb-ft)
Rated Current 30 Minute Output Amperes
Rotor Inertia kg-m 2 (lb.-in.-s 2 )
Bearing Load Max. Radial - kg (lb)
Motor Weight kg (lbs.)
Electrical Design
Vibration
Audible Noise
Feedback Device
Rated Ambient Temperature
Possible Mounting Methods
AFL-15
15 (20)
18.5 (25)
18.5 (25)
22 (30)
1500
6000
4:1
95 (70)
112
0.0925 (0.8186)
356 (784)
130 (286)
AFL-19
18.5 (25)
22 (30)
22 (30)
26.5 (36)
1500
6000
4:1
119 (87.5)
135
0.1150 (1.018)
373 (820)
150 (330)
AFL-22
22 (30)
30 (40)
27 (36)
36 (48)
1500
6000
4:1
142 (105)
153
0.1325 (1.173)
384 (844)
166 (365)
Single winding configuration for single speed range
Peak-to-peak vibration less than 3 microns (0.00012 inch-
es)
Less than 75dB (A Scale)
8 pole brushless resolver – 65,536 counts/revolution
0
°
to 40
°
C (+32
°
to +104
°
F)
Horizontal or vertical. Foot or flange mounting available 4
A22
26
112
Drive Model Number 8510A -
AC Input Voltage
Required AC Input 30 Minute Rating-kVA
Rated Output Current 30 Minute-Amperes
Power Control Method
Motor Braking Method
Input Command
Speed Control Range
Speed Regulation
Velocity Loop Bandwidth
Programming System
Drive Enclosure Type
Drive Weight kg (lb)
Allowable Vibration
Rated Ambient Temperature
Storage Temperature
A22
32
135
A22
40
153
PWM inverter using IGBT power devices
Power regeneration to the AC line
±
10V DC, 0-10V DC with Fwd/Rev input, 16 bit binary or BCD digital command
0 to 30,000 rpm, velocity resolution greater than 1:2,000,000
Transient change < 0.4% of max speed, steady state change < 0.025% (load: 10%-100%)
Up to 50 Hz (load and motor dependent)
Integral 2 line by 16 character backlit LCD display and 4 button keypad
Open style (IP-00) for mounting in another enclosure, heat sinks extend outside enclosure
Less than 0.5 G
0 to 55
°
C (32 to 131
°
F) inside enclosure, 0 to 40
°
C (32 to 104
°
F) at heat sinks
0 to 65
°
C (32 to 149
°
F)
200 to 220V AC (
±
10%) at 50/60 Hz. (
±
1 Hz) and 230V AC (
±
10%) at 60 Hz. (
±
1
Hz)
52 (114) 52 (114) 52 (114)
1 30 minutes starting with cold motor.
2 Loaded for 60% of a 10 minute cycle.
3 15 minute rating for 1327AB-AFM-02 motor.
4 1327AB-AFM-02 and 1327AD-ACL-08 only available as flange mount and 1327AD-ABL-08 only available as foot mount.
