Dimensions
Chapter 3
3-31
Figure 3.14
High Resolution Magnetic Feedback – Sensing Head
70 Max.
38 Max.
33
Max.
Minimum Length = 2,000
7 ±1
4 ±0.1
50 ±0.1
5.3 Dia., 2 Plcs.
0.9 ±0.3
22.2 Dia.
±0.2
4.9 ±0.5
5 Max.
16.5
9
9
11 +0/–0.02
Z Phase Sensor Center
A/B Phase Sensor Center
