Enter Your Values Here
Load Initial Configuration Values
Chapter 7
7-15
Worksheet 7ĆF (continued)
Pack Configuration Block (PKC)
Control Word ProĆSet 600 Addr. Value
Description
Units
PKC06
N44:122
1000
Minimum ERC PercentageĆĆPressure
Percent
8
PKC09
N44:125
*
Output #1 SetĆoutput Value During Profile
Percent Signal Output
4
PKC10
N44:126
*
Output #2 SetĆoutput Value During Profile
Percent Signal Output
4
PKC11
N44:127
*
Output #3 SetĆoutput Value During Profile
Percent Signal Output
4
PKC12
N44:128
*
Output #4 SetĆoutput Value During Profile
Percent Signal Output
4
PKC17
N44:133
0
Output #1 Acceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC18
N44:134
0
Output #2 Acceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC19
N44:135
0
Output #3 Acceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC20
N44:136
0
Output #4 Acceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC25
N44:141
0
Output #1 Deceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC26
N44:142
0
Output #2 Deceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC27
N44:143
0
Output #3 Deceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC28
N44:144
0
Output #4 Deceleration Ramp Rate During Profile
Percent Signal Output per Second
5
PKC41
N44:157
0
Pressure Minimum Control Limit
Pressure
3
PKC42
N44:158
*
Pressure Maximum Control Limit
Pressure
3
PKC43
N44:159
*
Selected Pressure Valve, Output for Minimum
Percent Signal Output
4
PKC44
N44:160
*
Selected Pressure Valve, Output for Maximum
Percent Signal Output
4
PKC49
N44:165
100
Proportional Gain for Pressure Control
None
PKC50
N44:166
400
Integral Gain for Pressure Control
Inverse Time (Algorithm)
6
PKC51
N44:167
0
Derivative Gain for Pressure Control
Time (Algorithm)
7
PKC57
N44:173
0
Profile High Pressure Alarm Setpoint
Pressure
3
3
Pressure
4
Percent Signal Output
0000 to 9999 PSI 00.00 to 99.99
000.0 to 999.9 Bar
5
Percent Signal Output per Second
6
Inverse Time (Algorithm)
7
Time (Algorithm)
8
Percent
0000 to 9999 00.00 to 99.99 Minutes (ISA) 00.00 to 99.99 Minutes (ISA) 00.00 to 99.99
00.00 to 99.99 Seconds (AĆB) 00.00 to 99.99 Seconds (AĆB)
* Refer to the appropriate section later in this chapter for information on this parameter
