Chapter 7
7-25
Worksheet 7ĆK (continued)
Third Clamp Open Configuration Block (TOC)
Control Word ProĆSet 600 Addr. Value Description Units
TOC05 N43:421 1000 Minimum ERC PercentageĆĆVelocity Percent 8
TOC06 N43:422 1000 Minimum ERC PercentageĆĆPressure Percent 8
TOC08 N43:424 0 Profile Watchdog Timer Preset Time 1
TOC09 N43:425 * Output #1 SetĆOutput Value during Profile Percent Signal Output 3
TOC10 N43:426 * Output #2 SetĆOutput Value during Profile Percent Signal Output 3
TOC11 N43:427 * Output #3 SetĆOutput Value during Profile Percent Signal Output 3
TOC12 N43:428 * Output #4 SetĆOutput Value during Profile Percent Signal Output 3
TOC17 N43:433 0 Output #1 Acceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC18 N43:434 0 Output #2 Acceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC19 N43:435 0 Output #3 Acceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC20 N43:436 0 Output #4 Acceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC25 N43:441 0 Output #1 Deceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC26 N43:442 0 Output #2 Deceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC27 N43:443 0 Output #3 Deceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC28 N43:444 0 Output #4 Deceleration Ramp Rate during Profile Percent Signal Output per Second 4
TOC33 N43:449 * Output #1 SetĆOutput Value at EndĆof Profile Percent Signal Output 3
TOC34 N43:450 * Output #2 SetĆOutput Value at EndĆof Profile Percent Signal Output 3
TOC35 N43:451 * Output #3 SetĆOutput Value at EndĆof Profile Percent Signal Output 3
TOC36 N43:452 * Output #4 SetĆOutput Value at EndĆof Profile Percent Signal Output 3
TOC41 N43:457 0 Pressure Minimum Control Limit Pressure 2
TOC42 N43:458 * Pressure Maximum Control Limit Pressure 2
TOC43 N43:459 * Selected Pressure Valve, Output for Minimum Percent Signal Output 3
TOC44 N43:460 * Selected Pressure Valve, Output for Maximum Percent Signal Output 3
TOC45 N43:461 0 Velocity Minimum Control Limit Velocity along Axis 5
TOC46 N43:462 * Velocity Maximum Control Limit Velocity along Axis 5
TOC47 N43:463 * Selected Velocity Valve, Output for Minimum Percent Signal Output 3
TOC48 N43:464 * Selected Velocity Valve, Output for Maximum Percent Signal Output 3
TOC49 N43:465 100 Proportional Gain for Pressure Control None
TOC50 N43:466 400 Integral Gain for Pressure Control Inverse Time (Algorithm) 6
TOC51 N43:467 0 Derivative Gain for Pressure Control Time (Algorithm) 7
TOC52 N43:468 200 Proportional Gain for Velocity Control Inverse Time (Algorithm) 6
TOC53 N43:469 0 Feed Forward Gain for Velocity Control None
TOC57 N43:473 0 Profile High Pressure Alarm Setpoint Pressure 2
1 Time 2 Pressure 3 Percent Signal Output 4 Percent Signal Output per Second
00.00 to 99.99 Seconds 0000 to 9999 PSI 00.00 to 99.99 0000 to 9999
000.0 to 999.9 Bar
5 Velocity along Axis 6 Inverse Time (Algorithm) 7 Time (Algorithm) 8 Percent
00.00 to 99.99 Inches per Second 00.00 to 99.99 Minutes (ISA) 00.00 to 99.99 Minutes (ISA) 00.00 to 99.99
000.0 to 999.9 Millimeters per Second 00.00 to 99.99 Seconds (AĆB) 00.00 to 99.99 Seconds (AĆB)
* Refer to the appropriate section later in this chapter for information on this parameter
