Span Your Valves
Chapter 9
9-9
Span your clamp close pressure valve(s) for optimum performance. Do
this in four parts:
Confirm critical values
Span your clamp close pressure valve(s)
Test valve linearity
Set pressure alarm setpoints
Important: You may omit the next three parts of this section if you have
the right information on valve spanning. Many injection molding machine
OEMs and hydraulic valve manufacturers provide data on spanning the
working range of valves used on their machines. If this information is
available from your OEM for your machine’s clamp close pressure
valve(s), enter the values into pressure control limits FCC41-44,
SCC41-44, and TCC41-44 and proceed to Set Profile Pressure Alarms.
Confirm Critical Values
Important: Confirm that your entries for configuration values (chapter 7)
and profile values (chapter 8) for clamp close profiles are as follows:
On Worksheet: Confirm Your Configuration: With These Words or Bits: ProĆSet Addr.:
7ĆA, 7ĆB, 7ĆC QDC module output to which you connect
your selected pressure control valve
FCC02ĆB06,B05,B04 = your selection
SCC02ĆB06,B05,B04 = your selection
TCC02ĆB06,B05,B04 = your selection
B37/22, 21, 20
B37/86, 85, 84
B37/150,149,148
Your unselected setĆoutput values for outputs
1Ć4
FCC09Ć12 = your values
SCC09Ć12 = your values
TCC09Ć12 = your values
N43:5Ć8
N43:65Ć68
N43:125Ć128
All ramping is disabled with zero ramp rates FCC17Ć20 = FCC25Ć28 = 0,
SCC17Ć20 = SCC25Ć28 = 0
TCC17Ć20 = TCC25Ć28 = 0
N43:13Ć16 N43:21Ć24
N43:73Ć76 N43:81Ć84
N43:133Ć136 N43:141Ć144
Pressure limits:
Minimum Control Limit
Maximum Control Limit
Selected Pressure Valve, Output for Min
Selected Pressure Valve, Output for Max
FCC41=SCC41=TCC41=0
FCC42=SCC42=TCC42=your value
FCC43=SCC43=TCC43=your value
FCC44=SCC44=TCC44=your value
N43:37, 97, 157
N43:38, 98, 158
N43:39, 99, 159
N43:40, 100, 160
8ĆA Pressure vs. Position Control CPC03ĆB04 = B02 = B00 = 1 B37/292, 290, 288
Logical bridge CPC03ĆB10, B09, B08 = 0 B37/298, 297, 296
Mold Protection CPC03ĆB11 = 0 B37/299
OpenĆloop control CPC04ĆB07 = B05ĆB00 = 1 B37/311, 309Ć304
Expert Response Compensation (ERC) = Off CPC04ĆB15 = B13ĆB08 = 1 B37/319, 317Ć312
FCC pressure setpoints CPC10, 13, 16 = your value N43:246, 249, 252
FCC endĆofĆsegment position setpoints CPC11, 14, 17 = your value N43:247,250,253
Start LPC position CPC61 = your value N43:297
Mold Safe Position CPC62 = your value N43:298
If these are not your current values, we suggest that you correct them now
using the download procedure discussed in chapter 4.
Span Your Clamp Close
Pressure Valve(s)
