Select Command and Status Bits
to Sequence Machine Operation
Chapter 6
6-6
Table 6.F
Status Bits
Category: Bit Status
(when = 1):
ProĆSet
B34/xx:
QDC Block
Addr.:
Jog Status executing unassigned #1 jog 09 SYS01ĆB09
executing ram (screw) forward jog 10 SYS01ĆB10
executing ram (screw) reverse jog 11 SYS01ĆB11
executing clamp forward jog 12 SYS01ĆB12
executing clamp reverse jog 13 SYS01ĆB13
executing unassigned #6 jog 14 SYS01ĆB14
executing unassigned #7 jog 15 SYS01ĆB15
Profile Complete 1st clamp close profile complete 16 SYS02ĆB00
2nd clamp close profile complete 17 SYS02ĆB01
3rd clamp close profile complete 18 SYS02ĆB02
LP close profile complete 19 SYS02ĆB03
injection profile complete 20 SYS02ĆB04
pack profile complete 21 SYS02ĆB05
hold profile complete 22 SYS02ĆB06
preĆdecompress movement complete 23 SYS02ĆB07
plastication profile complete 24 SYS02ĆB08
postĆdecompress movement complete 25 SYS02ĆB09
1st clamp open profile complete 26 SYS02ĆB10
2nd clamp open profile complete 27 SYS02ĆB11
3rd clamp open profile complete 28 SYS02ĆB12
clamp open slow profile complete 29 SYS02ĆB13
Busy Status no action (outputs at zero) 31 SYS02ĆB15
Miscellaneous Status clamp in mold protection zone 32 SYS03ĆB00
mold safe 33 SYS03ĆB01
tonnage complete 34 SYS03ĆB02
cure timer timing 35 SYS03ĆB03
ram (screw) retracted 36 SYS03ĆB04
cure time complete 37 SYS03ĆB05
clamp in openĆslow zone 38 SYS03ĆB06
mold open 39 SYS03ĆB07
mold openĆdwell timer is timing 41 SYS03ĆB09
cycle complete 43 SYS03ĆB11
