Select Command and Status Bits
to Sequence Machine Operation
Chapter 6
6-9
Table 6.G
Command and Configuration Bits
Operation: Function Enabled
(when = 1):
ProĆSet
B34/xx:
QDC Block
Addr.:
NonĆprofiled execute setĆoutput 392 DYC01ĆB08
Action Commands execute ram (screw) forward jog 393 DYC01ĆB09
execute ram (screw) reverse jog 394 DYC01ĆB10
execute unassigned # 3 jog 395 DYC01ĆB11
execute clamp forward jog 396 DYC01ĆB12
execute clamp reverse jog 397 DYC01ĆB13
execute unassigned #6 jog 398 DYC01ĆB14
execute unassigned #7 jog 399 DYC01ĆB15
Stop Command execute all stop (outputs = zero) 415 DYC02ĆB15
Miscellaneous reset tonnage watchdog timer 416 DYC03ĆB00
Commands reset cure timer 417 DYC03ĆB01
reset SYS01ĆB08 424 DYC03ĆB08
reset latched alarms 425 DYC03ĆB09
reset complete bits 426 DYC03ĆB10
Profile Action execute 1st clamp close profile 400 DYC02ĆB00
Commands execute 2nd clamp close profile 401 DYC02ĆB01
execute 3rd clamp close profile 402 DYC02ĆB02
execute LP clamp close profile 403 DYC02ĆB03
execute injection profile 404 DYC02ĆB04
execute pack profile 405 DYC02ĆB05
execute hold profile 406 DYC02ĆB06
execute preĆdecompression movement 407 DYC02ĆB07
execute plastication profile 408 DYC02ĆB08
execute postĆdecompression movement 409 DYC02ĆB09
execute 1st clamp open profile 410 DYC02ĆB10
execute 2nd clamp open profile 411 DYC02ĆB11
execute 3rd clamp open profile 412 DYC02ĆB12
execute clamp open slow profile 413 DYC02ĆB13
