8ć23 – Rockwell Automation 1771-QDC, D17716.5.86(Passport) PLASTIC MOLDING MODULE User Manual
Page 144
Load Initial Profile Values
Chapter 8
8-23
Use Worksheet 8-D to enter setpoints for a backpressure vs. position
plastication profile. The valve spanning procedures in chapter 9 require
specific values. We have already entered many values for you, and help
you determine other values in the text that follows.
Determine and Enter
Setpoints
for Plastication Profile (PPC)
