Load Initial Configuration Values
Chapter 7
7-40
After you determine your initial values and enter them on configuration
worksheets, you are ready to proceed.
1. Enter all worksheet values into your PLC-5 data table.
Important: Be sure that you have not altered any setpoints, and that you
have entered each and every setpoint exactly as on the worksheets.
2. Use the procedure described in chapter 4 to download command
blocks to the QDC module. For your convenience, we repeat the
table of download information (Table 7.B) from chapter 4.
Important: Do not download companion blocks at this time.
Table 7.B
Information Required to Download a Block
Block to
Download:
ProĆSet 600
Block ID.:
ProĆSet 600 Download
Command Bit in B21:
FCC 03 2
SCC 04 3
TCC 05 4
LPC 06 5
INC 08 7
PKC 10 9
HDC 11 10
PLC 14 13
FOC 17 16
SOC 18 17
TOC 19 18
OSC 20 19
Enter and Download your
Worksheet Values
