AT-WL2411 Installation and User’s Guide
40
To perform a basic configuration of the AT-WL2411 using the default
settings, you need the following:
❑ An RS-232 null-modem cable.
❑ A terminal or PC with an open serial port.
To configure the AT-WL2411:
1. Use the RS-232 null-modem cable to connect the serial port on the
access point to a serial port on your PC.
2. Open your communications program and configure the serial
communications parameters on your PC to:
Baud 9600
Data bits 8
Parity no
Stop bit 1
Flow control none
3. Connect the power cable to the access point and to a power source.
The access point does not have an On/Off switch, so the unit boots as
soon as you apply power.
4. Press Enter when the message "Starting system" appears on your PC
screen. The login screen appears, as shown in Figure 11.
Figure 11 Login Screen
