AT-WL2411 Installation and User’s Guide
130
Configuring the Internal RADIUS Server
The access point has an internal RADIUS password server you can use to
authorize user name and password logins. By using this password server
you do not need to buy a separate server to authorize logins, but you are
limited to 70 users.
Note
Currently, you cannot use the internal RADIUS server as an 802.1x
authentication server.
To configure the internal RADIUS server:
1. From the main menu, click Security and then click Internal RADIUS
Server. The Internal RADIUS Server screen appears as shown in Figure
58.
Figure 58 Internal RADIUS Server
2. If Server is disabled, click the down arrow on the right side of the
Server field and then choose Enabled. Click Submit Changes.
3. In the Secret Key field, enter the key from 1 to 32 characters in ASCII
or in hexadecimal. To enter a hexadecimal key, it must start with 0x.
4. Click Submit Changes.
