AT-WL2411 Installation and User’s Guide
101
DIX IP Other Protocols
SNAP IP Other Protocols
IP protocols other than TCP or User Datagram Protocol (UDP).
DIX IPX Sockets
Novell NetWare protocol over Ethernet II frames.
SNAP IPX Sockets
Novell NetWare protocol over 802.2 SNAP frames.
802.3 IPX Sockets
Novell NetWare protocol over 802.3 RAW frames.
DIX Other Ethernet Types
SNAP Other Ethernet Types
DIX or SNAP registered protocols other than IP or IPX.
802.2 IPX Sockets
Novell running over 802.2 Logical Link Control (LLC).
802.2 Other SAPs
802.2 SAPs other than IPX or SNAP.
Note
If you set the Scope field to Unlisted for any of the frame types, you
must also configure predefined subtype filters or customizable
subtype filters. For help, see Using Predefined Subtype Filters on
page 101 or Customizing Subtype Filters on page 102.
Note
You cannot filter HTTP, Telnet, SNMP, and ICMP frames, because
they are used for configuration and management of the access
point. Additionally, you cannot filter broadcast ARP request packets
if the target IP address belongs to the local access point or to an
access point in the subtree rooted at the local access point.
5. Click Submit Changes to save your changes. To activate your changes,
click the Save/Discard Changes link in the menu bar and then click
Save Changes and Reboot. For help, see Saving Your Configuration
Changes on page 46.
Using Predefined Subtype Filters.
You can configure the access point to pass or drop certain predefined
frame subtypes.
To configure predefined subtype filters:
