4. Remove the punch-out tab from the door, as shown in Figure 10.
Figure 10 Punch-out Tab
5. Attach the antenna cable to the radio by inserting the cable
connector into the radio card.
6. Replace the door.
Punch-out
tab
Pliers
Door
