AT-WL2411 Installation and User’s Guide
184
IP Tunnels Menu Default Settings
Tunnel Filters
Parameter Name Range Default
Port Control Enabled/Disabled Enabled
Mode Listen/Originate If
Root Originate If Root
IGMP Enabled/Disabled Disabled
Hello Period 1, 2, or 3 Seconds 2
Frame Type Filters
Action Pass/Drop Drop
Scope Unlisted/All Unlisted
Predefined Subtype
Filters
Action Pass/Drop Drop (except Pass for
NNL)
Customizable
Subtype Filters
Action Pass/Drop Drop
Subtype DIX-IP-TCP-Port,
DIX-IP-UDP-Port,
DIX-IP-Protocol,
DIX-IPX-Socket,
DIX-EtherType,
SNAP-IP-TCP-Port,
SNAP -IP-UDP-Port,
SNAP -IP-Protocol,
SNAP -IPX-Socket,
SNAP -EtherType,
802.3-IPX-Socket,
802.2 -IPX-Socket, or
802.2-SAP DIX-IP-TCP-Port
Value Two sets of
hexadecimal pairs 00
through FF 00 00
